NF-280 Corn Peeler, Degerminator and Polisher

Product properties
  • Summary:NF-280 corn peeler and polisher is internally installed 380V motor with 7.5W and can process 500kg of corn, wheat, sorghum and rice per hour.

NF-280 Corn Peeler and Polisher:
1.Used in corn peeling, wheat peeling, paddy peeling and sorghum peeling.
2.Suitable for small size of food processing factories in corn, wheat and sorghum peeling.







NF-280 Corn Peeler and Polisher working principle:
NF-280 corn peeler and polisher is internally installed 380V motor with 7.5W and can process 500kg of corn, wheat, sorghum and rice per hour. After cleaning up, the unprocessed corn enters into the peeling chamber of NF-280 corn peeling and polishing machine through feeding port. By control the feeding speed at the feeding port and the pressure of the pressure valve, we make the peeling chamber have some pressure. The machine squeezes, peels, degerminates, removes impurities and polishes the material between the rotary roller and the screen. And under the pneumatic effect, the corn kernels and the bran separate automatically and then we can get qualified corn kernels. The machine is internally installed efficient air suction chamber which can remove the skin and impurities from the peeling process.

Features of NF-280 Corn Peeler and Polisher:
1. Easy structure, good manufacturability in processing and installation, small volume and convenient operation. The whole machine only occupies an area of less than one square meter and we only need to install pitch screw for fixing.
2. Wheat, sorghum and paddy peeling and polishing function.
3. Internally installed efficient winnowing and dust removing blower.
4. High output and good effect. The discharging port of the peeling chamber can accurately control corn or wheat staying time in the peeling chamber by pressure valve and ensure the effective friction with alloy roller so as to realize better peeling effect.

NF-280 Corn Peeler and Polisher End Products:

NF-280 Corn Skin Remover and Polisher


NF-280 Corn Peeler and Polisher Technical Parameter:

Type Capacity(kg/h) Power(kw) Speed(r/min) Weight(kg) Dimension(mm)
NF-280 corn peeilin 500-600 7.5 1000-1200 180 1000×400×1200
wheat peeling 600-700
milet polishing 1000-1500
​​​

VIDEO:

NF-280 Corn Skin Remover and Polisher
