YMSJ Corn Grits Grinder

Product properties
  • Summary:Corn Grits Grinder is the core equipment for producing corn grits. It has high corn grits yield.

YMSJ super fine Corn Grits Grinder introduction:
Corn grits grinder or corn grits grinding machine, corn grits milling machine, is the core equipment for producing corn grits. It has high grits yield.






Corn Grits Grinder Working principle:
This Corn Grits Grinder consists of rotor, upper and lower casing, pelletizing chamber, kneading toothed plate, sieve plate, motor and rack. When the raw material enters into the pelletizing chamber, under the strike and shearing effect of the professional shear type blade, the cut material kneads and strikes with the sieve plate by the centrifugal drive, which makes the granules surface smooth and makes them become arc shape. The material granules which are smaller than the sieve pore are discharged out of the machine, and granules which are bigger than the sieve pore continue to be cut and stroke until they can pass the sieve pore.

Corn Grits Grinder End Products:

Uniform granularity, bright color and smooth surface. Strong market competitiveness.


Corn Grits Grinder Technical Parameter:

Type Diameter of Rotor(mm) Spindle Speed(r/min) Power(kw) Capacity(t/h) Weight(kg) Rated Voltage(v) Dimension(mm)
YMSJ32×16 320 2500 7.5 1.2 200 380 1100×1100×1400
YMSJ40×18 400 2500 11 1.5 320 380 1200×1200×1500
YMSJ56×40 560 2500 22 2 500 380 1300×1300×1600
YMSJ60×60 600 2500 45 5 750 380 1450×1400×1700
